Pin Gauge Kit M6
PDM
| Quantity: | |
|---|---|
Features of M6 Pin Gauge .833" .916"
Precision Machinery Pin Gauges Title:
Minus steel pin gauge set high precision M6 pin gauges set .833 .916" 84 pcs
Core Structure and Components
The high-precision Pin height set is made of SKS-3 tool steel/tungsten carbide composite material, which has undergone deep cryogenic treatment and chrome protection, and is wear-resistant and corrosion-resistant, suitable for humid and oily environments. Needle gauge negative tolerance design (slightly smaller than the nominal value in actual testing), accurately detecting the minimum size of 0.011-1.000 inches (0.28-25.4mm) aperture, quickly identifying the risk of insufficient processing, assisting in determining the minimum allowable boundary, suitable for precision quality inspection of automotive fuel injectors/electronic connectors, etc., balancing efficiency and accuracy.
Specifications:
Diameter: 0.833-0.916 inch
Capacity: 84pcs/Set
Finish: Smooth & Anti-corrosion & Hard-wearing
Storage Case: M6 (Red Storage Case)
Gage Pin Display
Accuracy Testing
| Pin Gauge Set M6 Diameter,Inch,Minus | |||||||||
| 0.833 | 0.834 | 0.835 | 0.836 | 0.837 | 0.838 | 0.839 | 0.84 | 0.841 | 0.842 |
| 0.843 | 0.844 | 0.845 | 0.846 | 0.847 | 0.848 | 0.849 | 0.85 | 0.851 | 0.852 |
| 0.853 | 0.854 | 0.855 | 0.856 | 0.857 | 0.858 | 0.859 | 0.86 | 0.861 | 0.862 |
| 0.863 | 0.864 | 0.865 | 0.866 | 0.867 | 0.868 | 0.869 | 0.87 | 0.871 | 0.872 |
| 0.873 | 0.874 | 0.875 | 0.876 | 0.877 | 0.878 | 0.879 | 0.88 | 0.881 | 0.882 |
| 0.883 | 0.884 | 0.885 | 0.886 | 0.887 | 0.888 | 0.889 | 0.89 | 0.891 | 0.892 |
| 0.893 | 0.894 | 0.895 | 0.896 | 0.897 | 0.898 | 0.899 | 0.9 | 0.901 | 0.902 |
| 0.903 | 0.904 | 0.905 | 0.906 | 0.907 | 0.908 | 0.909 | 0.91 | 0.911 | 0.912 |
| 0.913 | 0.914 | 0.915 | 0.916 | ||||||
Application:
Semiconductor manufacturing: used for precision cavity aperture verification, ensuring smooth minimum gas/liquid channels, guaranteeing etching process stability and equipment reliability;
Automotive industry: Conduct quality inspection on the installation holes of turbocharger impellers, accurately control the minimum clearance, and avoid friction overheating and component failure caused by insufficient clearance;
In the field of optical instruments: implementing minimum size control for the fixed holes of the lens barrel, improving assembly accuracy, and ensuring consistent performance of the optical system.
Core advantages of the product:
Ultra precision detection: micrometer level resolution, accurately determining the minimum physical size of the aperture;
Ultra long lifespan: The wear resistance of the hard alloy needle gauge is increased by more than 3 times, suitable for high-frequency testing;
Multi scenario adaptation: covering aperture, depth, and position error detection in industries such as molds, electronics, and military;
