Pull Ring Hand Retractable Spring Plunger
PDM
| Quantity: | |
|---|---|
Features of Hand Retractable Spring Plunger
Retractable Indexing Plunger Title:
High Precise Hand Retractable Indexing Plunger retractable plunger
Hand Retractable Spring Plunger Introduction:
Main features of the product:
Operation mechanism: Adopting a manual pull ring design, users can easily retract the plunger by pulling the circular handle, providing convenient adjustment and release functions;
Materials and Surface Treatment: Products are typically made of high-strength materials such as carbon steel or stainless steel (such as Stainless Steel or Zinc Plated surfaces) to ensure wear resistance and corrosion resistance;
Surface treatment options include Black Ring or Plain to adapt to different working environments.
Model and specifications: Common models include M10 and M12, which support standard size applications;
| Carbon Steel | Stainless Steel | End Pressures (lbs) | |||||||
| Part No. | Part No. | Start | Full | Thread | I1 | I2 | d1 | D | I3 |
| HRP025-C | HRP025-S | 1.0 | 2.5 | 1/4-20 | 1.14 | 0.25 | 0.155 | 1.00 | 0.80 |
| HRP375-C | HRP375-S | 2.0 | 4.0 | 3/8-16 | 1.68 | 0.38 | 0.233 | 1.25 | 1.20 |
| HRP050-C | HRP050-S | 2.5 | 5.0 | 1/2-13 | 2.00 | 0.50 | 0.312 | 1.38 | 1.40 |
Application:
Usage: Widely used in industrial locking and indexing systems, such as fixing workpieces in production lines or achieving rapid transposition; Its Hand Retractable characteristic;
Product Definition and Details
Pull Ring: a ring shaped operating handle that allows users to manually control the extension and retraction of the plunger by pulling it; This design reduces tool dependency and makes the operation more user-friendly.
Hand Retractable: indicates that the plunger supports manual retraction function, which can be quickly reset or adjusted in position without the need for additional tools; Especially suitable for scenarios that require repeated positioning.
Spring Plunger: The core component is a spring-loaded plunger that provides holding force through internal spring pressure; When the pull ring is pulled, the spring compresses, the plunger retracts, and after release, it automatically resets to achieve locking;
